Add ons:

Aluminum Plate

Brass Plate

Solderable PCB

We have offered the options for WK case with 7u hot-swap PCB.

The 7u hot-swap PCB(ANSI/ISO) has the winkeys(1u) on it,you could place it into the WK case

We suggest customers to take videos when unboxing. (In case the product is damaged during shipping)

Specifications:

- Wired
- ANSI / ISO Layout
- WK / WKL
- Case Color: Black,Space Grey,Silver,Blue
- Programmable via QMK/VIA/Vial
- N-Key Rollover
- Gasket Mount Structure
- Compatible With MX Switches And Clones (3-pin&5-pin)
- South-facing Switches And LEDs
- Customizable RGB Using VIA/Vial Software
- 1.6 mm Thickness PCB
- PCB Mount Stabilizers (Not included)
- USB Type-C Connectivity
- Vortex Aluminum Badges
- Only Solderable PCB supports stepped Caps lock and Tsangan layout

Includes:

Aluminum Badge x2 (Vortex Logo And "VTK")

*Additional badge-"VTK" is only included in preorders

Top And Bottom Case x1
FR-4 Plate x1
Hot-swap PCB x1
USB Daughter Board x1
Plate Foam: 3mm x2 (Main PCB And F-row)
Poron switch Pad: 0.5mm x2 (Main PCB And F-row)
Bottom Case Sound-dampening Foam: 3mm x1 (Main PCB)
Gasket Set x1
M3 Scerw Set x1
Rubber Feet Set x1
Carrying Case x1

*Not Includes:

PCB Mount Stabilizers
Cable
Switches
Keycaps
Switch Puller
Keycap Puller

Slight scratches to a case or any components are acceptable to our quality standard.

If you have any problem or question, please contact your original vendor that you purchased from.

We use the same plate for both ANSI, ISO and Tsangan layout.
If you purchase any PCB with different layout for extras, you won't have to buy an additional plate.

Backlit:

- RGB

Product Size:

- L*W*H : 39.0*16.5*1.2 cm ± 0.3

-L*W*H : 39.0*16.5*3.0 cm ± 0.3

Product Weight:

- Case only : 1453.0 (g) ± 10

- All components added together: Approximately : 3kg

Typing Angle:

- 6°

Warranty:

*No warranty

NOTICE

※ All pictures shown are for illustration purpose only. Actual products may vary due to product enhancement.

※ Duties and taxes are not included in shipping fee.

※ Since this product is not a fully assembled keyboard, it could not be return, refund and doesn't include 12 months of warranty.

Pre-orders cannot be cancelled after the pre-order period has ended or after the pre-order has been closed!!!
